Automotive duct suction molding machine

Overview: This equipment is a five station integrated computer-controlled fully automatic XPE double-layer vacuum forming machine production line. The product model is YZ-1515/200. The equipment adopts a linear assembly line operation structure and is suitable for automatic continuous operation of double-layer thick sheet vacuum forming machines. The main purpose of the equipment is a specialized device for automotive air conditioning ventilation ducts.

Process: Automatic feeding of sheet material - Automatic calibration of sheet material - Clamping and heating of sheet material transmission (automatic) - Clamping and baking of material transmission - Dual mode step-by-step forming (automatic) - Simultaneous cutting of mold closing and hot pressing (automatic) - Cooling (automatic) - Backblowing demolding (automatic) - Dual mode separation (automatic) - Pick up (automatic) - Product falling into the silo and finished product flowing out

Main technical parameters

Forming area: 1500mm * 1500mm

Forming height: 200mm

Equipment total power: 150KW (normal usage power: 60KW)

Production speed: 30-50P/S (XPE ≤ 5mm)

Equipment applicable materials: XPE, IXPE

Product material thickness: 1.0-8.0mm

Equipment dimensions: L15500MM * W2800mm * H2900mm
