Blood bag heat sealing machine

1. This device is suitable for heat sealing with blood bag tubing and sealing blood samples

2. Function: Instant heat sealing, automatic control, uniform heat bonding, reliable and pollution-free

3. Timing range: 0.5-5S, heat sealing standard inlet: 5mm diameter plastic pipe

4. Equipment size: L300 * W155 * H235

5. Equipment weight: approximately 5KG

1. Power supply voltage: AC220V 50Hz
2. Rated power: 260W
3. Operating frequency: 40.68 MHz
4. Sealing speed: ≥ 20 times/minute
5. Weight: 5KG
6. Dimensions: 315 × 180 × 170 mm
7. Heat sealed object: Soft plastic tube for blood transfusion
8. Outer diameter of heat sealing tube: Φ 3~Φ 6mm
10. Heat sealing control form: automatic
11. ★ Cooling method: Air cooling
12. Environmental temperature: 5 ℃~35 ℃;
13. Relative humidity: ≤ 80%;
14. ★ Multiple voltage protection and filtering shielding design, safe and stable.
15. Multiple power protection devices, reliable performance, no need for preheating, easy operation.
16. Wide voltage design: AC90-260V 47-63Hz
17. Status indicator light: green: standby red: hot closed
18. The heat sealed surface does not require scissors, and can be easily separated by pulling lightly with your hand.
19. The seal is firmly sealed without leakage, contamination, or damage to the quality of the liquid.
20. Splash protection: A safe and effective transparent retractable splash protection sheet.
21. The heat sealing head is designed to be easy to clean, with a heat-insulating safety cover that can be easily disassembled and cleaned without the need for special tools.
