Large rotary welding and cutting machine

Scope of application: Suitable for automated production lines that require welding, cutting, and material extraction, such as processing pressure ulcer pads, oxygen pillows, etc.

Equipment features:

1. Four station dual head large turntable, welding and cutting integrated heat sealing machine, this equipment is divided into two heads, manual feeding/loading, one end is heat sealed and the other end is welded and cut simultaneously, and the last station is for material retrieval. The turntable diameter is 2.5 meters. Suitable for anti pressure ulcer pads, oxygen pillows, welding and cutting, large household coral fleece floor mats, carpet embossing, lettering, cutting and other processes, with high work efficiency, stability, and labor savings.

2. The equipment adopts a hydraulic system for pressurization, with a large and constant output and smooth operation. It is equipped with precision machined frames and spare parts, with a sturdy structure and good pressure resistance. The highly sensitive spark protection system can automatically cut off high-frequency current when sparks are generated, effectively protecting the equipment, molds, and products. The output force is strong, which can shorten the welding time. The turntable rotates automatically at a fast speed and high efficiency.
