Bubble shell packaging machine

Scope of application: Used for vacuum forming, welding, heat sealing, cutting and other processes of PVC, EVA, PETG, APET and other double foam or foam shells with paper cards.

Equipment features

1. The device is equipped with positive and negative pressure forming, butterfly hole punching (optional), cutting, feeding, paper card cutting, heat sealing, output and other power functions.
2. Adopting imported variable frequency control, color touch screen (human-machine interface), PLC programmable control system, high output, low noise, simple operation, and user-friendly.
3. Adopting servo motor infinite stroke control, the stroke adjustment is simple and the mold is easy to replace.
4. The lack of photoelectric control, PVC, and cardboard can cause buzzing alarms.
5. Adopting a separate design for convenient transportation and elevator access.
6. Each plastic device can save a lot of packaging materials.
