Automotive Interior Marking Machine

Equipment features: This machine can produce synthetic leather and microfiber leather embossing, suede interior package labeling, embossing and other processes. It adopts a servo control system, and the operating position is equipped with grating protection, which can be started by both hands. The repeated positioning accuracy reaches 0.03mm,

High frequency power: 8KW, electronic tube 3069

Upper plate size: 400 * 600

Lower pressure plate size: 700 * 450

Slide board size: 1000 * 600

Operating table to ground height: 920mm.

Pressure method: Air pressure SC100 * 200

Equipment power supply: 3-phase five wire system, AC380V/32A

Equipment dimensions: L2230 * W1160 * H1900 Weight: Approximately 950KG
